Deformation‐Based Support Design and Rockburst Hazard Assessment
By Peter K. Kaiser, Ming Cai and Dmitriy Malovichko
Course overview
As mines go deeper and get larger, underground excavations become more vulnerable to damage, and mine designs become more fragile. Therefore, ground control and rock support increasingly dominate construction schedules and production performance. Efficient and effective support becomes a strategic element of asset management because mine infrastructure and extraction developments are the most significant investments in a modern mine, particularly in caving operations. This investment must be protected and maintained to reduce the risk of ground failure related production disruptions (Moss and Kaiser, 2021). Furthermore, many mining companies working at great depth have identified seismic hazard as a corporate risk and consider ground control with cost-effective support systems a tactical tool for risk management. For this reason, it is of critical importance to forecast future mine performance, anticipate potential operational disruptions and additional costs as well as the anticipated effectiveness of support to ensure workplace safety.
Deformation-based support design (DBSD), as outlined by Kaiser and Moss (2021), offers a rational support design approach that overcomes deficiencies of standard ground motion-centric and energy-based support design approaches. It also provides a means to anticipate the effectiveness of a chosen support system during the life of a mine.
This course focuses on support design for excavations in brittle rock when displacements induced by sudden stress‐fracturing may consume much of the support’s capacity. It deals with the functionality of the support in deforming ground and with the consequences of mining‐induced support damage. It offers quantitative means to estimate the capacity of integrated support systems and a systematic approach to compare it with the static and dynamic demands imposed on the rock support.
Who should attend
This course aims at corporate clients with practical and operational experience and will not cover fundamental principles of geo‐engineering. Due to the technical content, the course is suitable for ground control engineers and technicians as well as mine seismologists, geologist and planners operating in seismically active mines. Furthermore, the course is designed for geotechnical consultants serving seismically active mining operators.
Delivery mode
This short course is presented in a virtual format in four modules covering both DBSD and RBHA. After an overview of design and evaluation procedures step‐by step instructions on how to adopt this innovative and integrated design approach are provided. Practical examples and case studies are used throughout the course to demonstrate the utility of DBSD and RBHA. Simplified analysis tools will be provided to the course participants to demonstrate the computation process and to facilitate sensitivity analyses.
Participants in this short course will be eligible for professional development (PD) hours (up to 16 hours). MIRARCO/Goodman School of Mines of Laurentian University can provide a certificate of attendance.
When:
On demand
Where:
Online
Hosted by MIRARCO Mining Innovation and Goodman School of Mines
Course fees:
US$1,250 / person
(Including documentation in pdf format and access to the computational tools).
Contact:
Peter K. Kaiser
info@geo-kaiser.ca
Ming Cai
mcai@laurentian.ca
Dmitriy Malovichko
dmitriy.malovichko@imsi.org
MIRARCO—Mining, Innovation, Rehabilitation and Applied Research Corporation, founded in 1998, is a not-for-profit applied research and technical service company formed through collaboration between Laurentian University and the private and public sectors. MIRARCO serves as an innovation bridge between researchers and industry.
The Goodman School of Mines serves as the gateway to Canada’s Mining University – Laurentian University. It is your one-stop access point to the most comprehensive mining education available in Canada, with an extensive array of undergraduate- and graduate- level programs, training and research geared to the full mining cycle.
How to register
For individual registration please click Register Course to register.
Discount is offered to individuals who took Module 1 DBSD course before. Please contact media@mirarco.org to obtain a discount code first and then click Register Course to register.
Discount is offered to corporations registering more than 3 individuals. Please send the names and email addresses of all participants from your organization to media@mirarco.org to register for the course. MIRARCO will send one invoice for the group registration to your company.
Course Information
Because gradual and sudden stress‐fracturing not only loads the support, but also deforms it, part of its load and energy dissipation capacity is gradually consumed leaving less and less remnant capacity at the time when the support is needed, i.e., during a rockburst. If the support capacity can be consumed by deformation, it can also be restored by preventive support maintenance (PSM). This concept for cost‐effective ground control is introduced and supported with operational evidence. Accounting for capacity consumption and integrating PSM into the mine development and operation schedule provide means for prudent asset management and opportunities for cost optimization.
Sudden stress‐fracturing of excavation walls emits seismic waves that can be used to identify the depth of strainbursting and the duration of the related rock mass bulking process. This provides essential input for support design in strainburst‐ prone ground, which is a new focus of this course.
The rockburst hazard in strainbursting ground depends on the stress level (stress at mining stages and strength in geological domains), the amount and rate of sudden stress fracturing, intensity of ground motion, and consumed support capacity (co‐seismic and mining‐induced strain). These and other factors are used to establish the current and to forecast the anticipated rockburst hazards. This is another new focus of this course.
This course presents an integrated approach of deformation‐ based support design (DBSD) using support demand and capacity assessment tools for areal support and bolting systems, and an innovative approach developed in collaboration with Newcrest Mining for rockburst hazard assessment (RBHA) using geological, stress, mining sequence, ground support, and seismic data.
The following tangible benefits can be derived from de-risking operations by a successful implementation of “deformation-based support design’”principles:
- improved workplace safety through real-time monitoring of consumed support capacity;
- improvement of resilience of support system through use of deformation compatibility criteria;
- reduction of operation delays through minimization of severe excavation damage;
- reduction of rehabilitation costs through proactive support maintenance; and
optimization of ground control measures in critical infrastructure.
The course consists of four modules. After an overview of design and evaluation procedures step‐by step instructions on how to adopt this innovative and integrated design approach are provided. Practical examples and case studies are used throughout the course to demonstrate the utility of DBSD and RBHA. Simplified analysis tools will be provided to the course participants to demonstrate the computation process and to facilitate sensitivity analyses.
The course instructors have revised and significantly updated the Canadian Rockburst Support Handbook (Kaiser et al., 1996) with a much stronger focus on strainburst assessment and related damage mitigation. Volume I of this revision has been released in 2018 as a Rockburst Support Reference Book (Cai & Kaiser, 2018). Volume II focusing on strainbursting is in preparation. Preliminary draft chapters will be distributed to course participants. Related publications providing background information or details of material presented will be available in pdf format.
Cai, M. & P.K. Kaiser, 2018. Rockburst support reference book. Volume I: Rockburst phenomena and support characteristics. MIRARCO, Laurentian University, Sudbury, Ontario. ISBN 978-0-88667-096-2. Free copies available from Rockburst Support Reference Book.
Kaiser, P.K. & M. Cai, (in preparation). Rockburst support reference book. Volume II: Rock Support to Mitigate Rockburst Damage Caused by Dynamic Excavation Failure. MIRARCO Laurentian University (draft manuscript released in 2019 and 2020).
Kaiser, P.K. & A. Moss, 2022. Deformation-based support design for highly stressed ground with a focus on rockburst damage mitigation. Journal of Rock Mechanics and Geotechnical Engineering 14(1): 50-66.
Moss, A. & P.K. Kaiser, 2022. An operational approach to ground control in deep mines. Journal of Rock Mechanics and Geotechnical Engineering 14(1): 67-81.
Kaiser, P.K., D.D. Tannant, D.D. & D.R. McCreath, 1996. Canadian Rockburst Support Handbook. Geomechanics Research Centre, Laurentian University, Sudbury, Ontario.
Preliminary course outline
Each module involves three to four hours of presentations with active interactions presented in a virtual delivery format. As much as possible, the course material will be tailored to the needs of the participant or hosting company or to the common support technologies adopted at the operations of the attendees.
Detailed description of course modules (Time will be set aside for Q&A periods (20 to 30 min per module)
Module 1 - Introduction to DBSD and RBHA
- Rockbursts and excavation failure processes
- Deficiencies of common support design approaches
- Overview of DBSD principles
- DBSD steps to overcome limitations of common ground motion centric design approach
- Integrated RBHA approach
- Motivation and justification of change in design method and need for change management
- Estimation of support demand
- Bolting system; areal support for shakedown and strainbursts
- Sensitivity to input and design parameters
- Case examples: general design rules for demand estimation
- Sensitivity and probabilistic approach using simplified computational engines
Module 2 - Support selection and capacity estimation
- Selecting the “right bolt” and areal support
- How bolts work?
- Support component properties (test procedures and selecting proper design parameters)
- Estimation of remnant capacity of integrated support systems
- Areal support and sensitivity to bolt spacing
- Estimation of bolting system capacity and capacity consumption
- Integrated support systems with areal support
- Preventive support maintenance (PSM)
- Gabion concept and capacity estimation
- Simplified computational engine to assess sensitivity to variability to design inputs
Module 3 - Step‐by‐step procedures for support design analysis
- Bolt length determination
- Shakedown analyses
- Intersection design (Canadian Rockburst Support Handbook (CRBSHB’96) approach)
- New shakedown design approach
- Self‐initiated and dynamically loaded strainburst support evaluation
- Assessment of support effectiveness
- Forecasting support damage and effectiveness of PSM
- Deterministic and probabilistic approach for support damage hazard assessment
- Proof of concept of DBSD approach
- Verification using displacement measurements
Module 4 – Support performance and seismic hazard
- Step‐by‐step analyses using computational engines
- Safety margin assessment for case examples
- Introduction of Rockburst Hazard Assessment (RBHA) model
- Hazard forecasting for different design stages, scenario assessment, determination of probability of exceedance and annual rate of exceedance
- Demonstration on case examples
- Spatial variation considering domain dependent inputs (mine geometry, geology, stress and support
